| 배양용기 (Supported labware) | 6 to 1536 well plates |
|---|---|
| 8 to 532 Pillar chip | |
| 330, 532 Microchip | |
| 이미징방식 (Imaging modes) | 4-channel fluorescence |
| 광원 (Light source) | High power Mercury lamp with adjustable intensity (>2,000 hours) |
| 광필터 (Available filters) | DAPI, GFP, SpGr, SPRED (Can be changed according to user needs) |
| 대물렌즈 (Compatible objectives) | 2-40X and 60X lens are available on request |
| 카메라 (Camera) | Type : CCD Pixel size : 4.4㎛ x 4.4㎛ (Can be changed according to user needs)
Pixel layout : 1624 x 1224 |
| 분해능 (Resolution) | X/Y Stage 1㎛ ; Z Stage 0.1㎛ |
